A7 Portable Magnetic Asset Tracking Device
A7 Portable Magnetic Asset Tracking Device
A7 Portable Magnetic Asset Tracking Device
A7 Portable Magnetic Asset Tracking Device

A7 Portable Magnetic Asset Car Tracking Device

A7 Portable Magnetic Asset Tracking Device to help you look out your asset’s location and movements if it is for personal or business use. Such as used for farm machinery, construction machinery, maritime equipment to caravans and so on. You can asset tracker your mapping platform from any device with an internet connection and then start receiving location information immediately.

  • Real-Time Positioning
  • Strong magnet and portable
  • Rechargable Battery
  • Support 3G network
  • Deep sleep and power –saving
  • Automatic power On/OFF
  • Ultra-strong waterproofing
  • Anti-detection,Anti-shielding
  • Concealed work, Smart operation
  • Tamper alarm
Categories: ,

Description

Portable Magnetic Asset Car Tracking Device

China OBD GPS Tracker ManufacturerRechargable Battery
Built-in rechargeable battery no worry about battery life

Strong Magnetic MountingStrong Magnetic Mounting
Stronger magnet allowing  faster mounting on metal surface

IP54 Dust and Waterproof Design|Vehicleknight GPS Tracking SystemIP67 Waterproof Design
Water resistance design ensure working in the harsh enviroment

Low Battery Alarm|Vehicleknight GPS Tracking SystemLow Voltage Alarm
When the battery voltage drops below threshold an alert will sent to owner

Multiple Alarms|Vehicleknight GPS Tracking SystemLight Perception Alarm
The light sensor detects light changes the device will send out a light perception alarm

BD02 Anti Theft GPS Vehicle Car Tracker

Specifications

Cellular Specifications
Communication System: GSM/WCDMA
GSM Frequency: 850/900/1800/1900 MHZ
WCDMA Frequency: 800/850/900/1900/2100MHz
GPRS: Class 12, TCP/IP
GPS Specifications
GPS Chip: U-Blox 7 High Performance Chipset
Channel: 66
Location Accuracy: <10meters
Tracking Sensitivity: -163dBm
Acquisition Sensitivity: -148dBm
GPS Location time: Cold Start<29s(open sky)Hot Start<1s(open sky)
Product Specifications
 GSM/GPS antenna:  Built-in quad band GSM antenna, GPS ceramic antenna
LED Indicator： GSM-Red, GPRS-Green, GPS-Blue
Work Voltage:  DC9-80V
Work Current:  ≤55mA
Standby Current: ≤15μA
Operating Temperature: -20℃ ~+70 ℃
Built-in Battery: 5000mAh  Industrial grade lithium polymer battery(Rechargeable)
Tracking Mode: >=3 years（Mode 1—one positioning/day ）

>=8-10days  (Mode 2-real time positionging)
Device Dimension: 60(W)*100(L)*24.5(H)mm
Device Weight: 180g

Download

Click to Download File
